Alignment Trainer Model F1

REAR CAMBER & TOE

Make a rear camber adjustment and see why it effects toe.

REAR TOE & THRUST ANGLE

See why rear toe affects thrust angle.

THRUST ANGLE EFFECT

See why thrust angle effects front toe bar graphs.

FRONT CAMBER

Make a front camber adjustment and see why it effects toe.

CASTER

Make a caster adjustment and see why it effects toe.

TOE & TOTAL TOE

Make simple toe adjustments and see it effect total toe.

CAMBER ROLL

See why camber changes on turns.

STEERING RETURN TO CENTER

See why the steering wheels returns to center.

CROSS CASTER

See why cross caster causes a pull.

ACKERMANN

See toe-out-on-turns in action.
